BSD / RCTA 415 |
|||||
|
. An icon appears on the center information display.
! Limitations of the detectability of RCTA s07bm010301
Since the detectability of RCTA is limited, the RCTA may not operate properly in angled parking.
Example 1
1 The detection range of the rear corner radars
2 Area out of detection range of the rear corner radars
A Vehicle that may not be detected B Parked vehicle
WARNING
An approaching vehicle( A) may not be detected because the detection
|
range is limited by the parked vehicle( B). Always be sure to check the surroundings with your eyes when reversing the vehicle. |
Example 2
1 The detection range of the rear corner radars
C Vehicle that may be detected
NOTE
The system may detect that a vehicle( C) is passing in front of your vehicle. Always be sure to check the surroundings with your eyes when reversing the vehicle.
|
& System Operation
s07bm02
! Operating conditions s07bm0201
The BSD / RCTA will operate when all of the following conditions are met.
. The ignition switch is in the“ ON” position.
. The BSD / RCTA warning indicator and BSD / RCTA OFF indicator are turned off.
. The vehicle is driven at speeds above 7 mph( 12 km / h)( except when reversing).
. The select lever is in the“ R” position( RCTA only).
The BSD / RCTA will not operate in the following situations.
. The BSD / RCTA OFF indicator appears.
. The vehicle speed is below 6 mph( 10 km / h) even when the BSD / RCTA OFF indicator does not appear( except when reversing).
NOTE
. In the following cases, the BSD / RCTA will stop operating and the BSD / RCTA warning indicator will appear. – When a malfunction occurs in the system, including the BSD / RCTA approach indicator light
– CONTINUED –
|
