Manual Climate Control 317 |
|||||
|
A
Models with rear ventilators
Heat-def: Windshield defroster outlets, foot outlets and both side outlets of the instrument panel
& Temperature Control s04ab05
Perform the following operation to regulate the temperature of airflow from the air outlets.
Temperature control buttons:
Press the temperature control button to the blue side( cool) or the red side( warm).
Temperature control screen( 11.6-inch display models):
1. Touch the climate control mode indicator.
2. Select the preferred temperature by the following operation.
|
. Touch and move the temperature control bar.. Touch“”/“”.. Touch the preferred temperature in the temperature control screen.
! Max A / C mode s04ab0503
For quicker cooling, touch“ MAX A / C” on the climate control mode select icon or customizable icon.
When the Max A / C mode is on, the following settings will be changed automatically.
. The air conditioner will turn on.
. The temperature will be set on the lowest.
. The fan speed will be set on the maximum speed.
. The air inlet will be set to the recirculation mode.
. The airflow mode setting will be set to the ventilation mode.
To turn off the Max A / C mode and return to the previous setting, touch“ MAX A / C” again.
NOTE
For models with the Driver Monitoring System, MAX A / C mode will be canceled if the Driver Monitoring System completes user recognition again while
|
MAX A / C mode is in use.
! SYNC mode( 11.6-inch display models) s04ab0505
When the SYNC mode is turned on, both the driver’ s and passenger’ s side temperatures are synchronized using the driver’ s side temperature control button and temperature control screen.
. If“ SYNC” is displayed on the customizable icon, touch“ SYNC” to turn the SYNC mode on or off.
. If a customizable icon other than“ SYNC” is displayed, touch the climate control mode indicator. Then touch“ SYNC” to turn the SYNC mode on or off.
When the SYNC mode is on, the SYNC mode indicator will be displayed. Touch“ SYNC” again, press the passenger’ s side temperature control button or operate the passenger’ s side temperature control bar to cancel the SYNC mode. When the SYNC mode is off, the SYNC mode indicator will no longer be displayed. In this case, temperature control on the driver’ s side and passenger’ s side will be separated. The temperature will be controlled individually using the driver’ s and passenger’ s temperature control button and the driver’ s and passenger’ s temperature control bar.
– CONTINUED –
|
4
Climate Control
|
