Mirrors 283 |
|||||
|
the device during the“ cycling” process to prevent possible overheating.
Proceed with“ Programming a New HomeLink ® button” step 4 to complete.
! Using HomeLink ® s03ap100303
To operate, simply press and release the programmed HomeLink ® button. Activation will now occur for the trained device( i. e. garage door opener, gate operator, security system, entry door lock, home / office lighting, etc.). For convenience, the hand-held remote of the device may also be used at any time.
! Erasing HomeLink ® buttons s03ap100304
To erase programming from the three buttons( individual buttons cannot be erased but can be“ reprogrammed” as outlined below), follow the step noted:
Press and hold the two outer HomeLink ® buttons for at least 10 seconds. The LED indicator will change from continuously lit to rapidly flashing. Release both buttons. Do not hold for longer than 20 seconds. HomeLink ® is now ready to be programmed at any time beginning with“ Programming a New HomeLink ® button”- step 1.
|
! Reprogramming a Single HomeLink ® button s03ap100305
To program a previously trained button, follow these steps:
1. Press and hold the desired HomeLink ® button. DO NOT release the button.
2. The indicator light will begin to slowly flash orange after 20 seconds. The HomeLink ® button can be released at this point. Proceed with“ Programming a New HomeLink ® button”- step 3.
3. If you do not complete the programming of a new device to the button, it will revert to the previously stored programming.
! Garage Door Two-Way Communication s03ap100306
HomeLink ® has the capability of communicating with your garage door opener. HomeLink ® can receive and display“ closing” or“ opening” status messages from compatible garage door opener systems. At any time, HomeLink ® can also recall and display the last recorded status communicated by the garage door opener to indicate your garage door being“ closed” or“ opened”.
HomeLink ® has the capability of receiving this communication from the garage door opener at a range up to 820 feet( 250 m).
|
Range may be reduced by obstacles such as houses or trees. You may have to slow your vehicle speed to successfully receive the garage door opener communication.
! Programming Two-Way Communication s03ap100307
1 Status Indicators
Within 5 seconds after programming a new HomeLink ® button, both of HomeLink’ s garage door status indicators will flash rapidly green indicating that the garage door two-way communication has been enabled. If your garage door status indicators flashed, two-way communication programming is complete.
If the garage door status indicators do not flash, additional HomeLink ® information and programming videos can be found
– CONTINUED –
|
3
Instruments and Controls
|
