Center Information Display ( CID ) 219 |
|||
|
! Touch screen
s03bs0501
1 HOME icon ( Refer to “ HOME icon ” FP226 .)
2 Status bar ( Refer to “ Status bar ” FP219 .)
3 Information bar ( Refer to “ Information bar ” FP220 .)
|
4 Main screen ( Refer to “ Main screen ” FP226 .)
5 Manage device icon ( Refer to the separate navigation / audio Owner ’ s Manual )
6 Driver profiles icon ( Refer to “ Driver profiles icon ” FP226 .)
7 Auto Start Stop ON / OFF icon ( Refer to “ Auto Start Stop ON / OFF icon ” FP222 .)
8 Climate control screen ( Refer to “ Climate control screen ” FP226 .)
9 Auto Vehicle Hold ( AVH ) ON / OFF icon ( Refer to “ Auto Vehicle Hold ( AVH ) ON / OFF icon ” FP223 .)
10 Car settings icon ( Refer to “ Car settings icon ” FP224 .)
While the ignition switch is in the “ ACC ” or “ ON ” position , the touch panel will activate .
! Status bar s03bs050101
The outside temperature and clock are displayed on the status bar .
NOTE
. The outside temperature indicator shows the temperature around the sensor . However , the temperature may not be indicated correctly or the update may be delayed in the following conditions . – While parking or driving at low speeds
– When the outside temperature changes suddenly ( example : when going in and out of an
|
underground parking area or when passing through a tunnel )
– When starting the engine after being parked for a certain period of time
. You can set the temperature units to be displayed in Celsius ( 8C ) or Fahrenheit ( 8F ). For details , refer to “ General settings ” FP227 .
. The clock can be displayed in either 12-hour display or 24-hour display . For details , refer to “ General settings ” FP227 .
. Touch the clock on the status bar to display the clock setting screen . Refer to “ Clock ” FP257 .
. For details about Bluetooth device information , refer to the navigation / audio Owner ’ s Manual .
|
3
Instruments and Controls
|
– CONTINUED – |
