Warning and Indicator Lights 193 |
|||||||
|
! Electronic Brake Force Distribution ( EBD ) system warning s03ae1003
If the warning light remains on even though the parking brake is released , the brake fluid level may be low or there could be a problem with the EBD system . Park the vehicle in a safe place immediately and contact a SUBARU dealer .
! Electronic brake booster warning s03ae1009
The brake system warning light illuminates when the electronic brake booster is malfunctioning . In addition , the warning messages “ Brake System ” and “ Check Owner ’ s Manual ” are displayed alternately on the combination meter display ( color LCD ). If the warning light illuminates , promptly park in a safe location as soon as possible and contact your SUBARU dealer .
! Electronic parking brake system warning s03ae1004
The brake system warning light illuminates when the electronic parking brake system is malfunctioning . If the warning light illuminates , promptly park in a safe location as soon as possible and contact your SUBARU dealer .
The brake system warning light remains illuminated when the parking brake cannot be released even if the parking brake switch is pushed . For details , refer to
|
“ Electronic Parking Brake ” FP394 .
! Frequent operation warning s03ae100403
The brake system warning light illuminates and a chirp sound will be heard if the parking brake switch is operated too frequently . In this case , the operation of the parking brake switch is restricted to protect the electronic parking brake system .
|
& Electronic Parking Brake Indicator Light
s03ae85
! Parking brake indicator s03ae8501
The light illuminates with the parking brake applied while the ignition switch is in the “ ACC ” or “ ON ” position . It turns off when the parking brake is fully released .
! Electronic parking brake system warning s03ae8502
WARNING
|
. When you release the electronic parking brake while the engine is running , the electronic parking brake indicator light will turn off . However , if the light still illuminates , stop the vehicle in a safe location immediately and have the system inspected by a |
SUBARU dealer .
. If at all in doubt about whether the brakes are operating properly , do not drive the vehicle . Have your vehicle towed to the nearest SUBARU dealer for repair .
. If the electronic parking brake indicator light flashes , the electronic parking brake system may be malfunctioning . Immediately stop your vehicle in a safe location , use tire stops under the tires to prevent the vehicle from moving and contact your SUBARU dealer . For details , refer to “ Electronic Parking Brake ” FP394 .
NOTE
. When the ignition switch is turned to the “ LOCK ”/“ OFF ” position with the electronic parking brake applied , the electronic parking brake indicator light remains illuminated for approximately 30 seconds and then turns off .
. When the electronic parking brake switch is pulled to apply the electronic parking brake while the ignition switch is in the “ LOCK ”/“ OFF ” position , the electronic parking brake indicator light illuminates , remains
|
3
Instruments and Controls
|
||
– CONTINUED – |
