Warning and Indicator Lights 189 |
||||||||||||||||
|
& Charge Warning Light s03ae05
If this light illuminates when the engine is running , it may indicate that the charging system is not working properly .
If the light illuminates while driving or does not turn off after the engine starts , stop the engine at the first safe opportunity and check the alternator belt . If the belt is loose , broken or if the belt is in good condition but the light remains illuminated , contact your nearest SUBARU dealer immediately .
|
& Oil Pressure Warning Light
CAUTION
|
s03ae06
Do not operate the engine with the oil pressure warning light on . This may cause serious engine damage .
If this light illuminates when the engine is running , it may indicate that the engine oil pressure is low and the lubricating system is not working properly .
If the light illuminates while driving or does not turn off after the engine starts , stop the engine at the first safe opportunity and contact your nearest SUBARU dealer immediately .
|
For details about checking the engine oil level or adding the engine oil , refer to “ Engine Oil ” FP527 .
& Engine Low Oil Level Warning Light s03ae58
This light illuminates when the engine oil level decreases to the lower limit .
If the warning light illuminates , check the engine oil level on a level surface . When the engine oil level is not within the normal range , refill with engine oil . Refer to “ Engine Oil ” FP527 . After adding or changing the engine oil , warm up the engine and stop it on a level surface , then start the engine after a lapse of 1 minute or more . Confirm that the warning light has turned off after the engine has started . If the warning light does not turn off after refilling the engine oil , or the light illuminates even though the engine oil level is within the normal range , have the vehicle checked by a SUBARU dealer .
NOTE
. The oil level will be detected by the system just after turning the ignition switch to the “ OFF ” position . If the oil level is below the lower limit when the ignition switch is turned to the “ ON ” position , the engine low oil level warning light will turn on .
|
. When the vehicle is parked on a steep slope , the engine low oil level warning light may not illuminate even if the oil level is below the lower limit to avoid erroneous lighting . |
& AT OIL TEMP Warning Light s03ae07
If this light illuminates when the engine is running , it may indicate that the transmission fluid temperature is too hot .
If the light illuminates while driving , immediately stop the vehicle in a safe place and let the engine idle until the warning light turns off .
! Transmission control system warning s03ae0701
If the “ AT OIL TEMP ” warning light flashes after the engine has started , it may indicate that the transmission control system is not working properly . Contact your nearest SUBARU dealer for service immediately .
|
& Low Tire Pressure Warning Light ( U . S . - Spec . Models ) s03ae08
When the ignition switch is turned to the “ ON ” position , the low tire pressure warning light will illuminate for approximately 2
|
3
Instruments and Controls
|
|||||||||
– CONTINUED – |
