Warning and Indicator Lights 187 |
|||||||||||
|
injury .
. Flashing or flickering of the warning light
. No illumination of the warning light when the ignition switch is first turned to the “ ON ” position
. Continuous illumination of the warning light
. Illumination of the warning light while driving
For details about the components monitored by the warning light , refer to “ SRS Airbag System Monitors ” FP112 .
|
& Front Passenger ’ s Frontal Airbag ON and OFF Indicator Lights s03ae03
NOTE
For details about the operating conditions of SRS seat cushion airbag , refer to “ SUBARU Advanced Frontal Airbag System , SRS Seat Cushion Airbag , SRS Side Airbag and SRS Curtain Airbag ” FP91 .
|
Dual 7.0-inch display models
: Front passenger ’ s frontal airbag ON indicator light
: Front passenger ’ s frontal airbag OFF indicator light
|
11.6-inch display models : Front passenger ’ s frontal airbag ON indicator light
: Front passenger ’ s frontal airbag OFF indicator light
|
The front passenger ’ s frontal airbag ON and OFF indicator lights show you the status of the front passenger ’ s SRS frontal airbag .
The indicators are located as shown in the illustration .
When the ignition switch is turned to the “ ON ” position , both the ON and OFF indicator lights illuminate for 6 seconds during which time the system is checked . Following the system check , both indicators turn off for 2 seconds . After that , one of the indicators illuminates depending on the status of the front passenger ’ s SRS
|
3
Instruments and Controls
|
||||||
– CONTINUED – |
