104
SRS Airbag( Supplemental Restraint System Airbag)
! Examples of the types of accidents in which the driver’ s / driver’ s and front passenger’ s SRS frontal airbag( s) are not designed to deploy in most cases s01ah021104
frontal airbags are not designed to deploy in most of the following cases.
. If the vehicle is struck from the side or from behind
. If the vehicle rolls onto its side or roof
. If the vehicle is involved in a low-speed frontal collision once either or both of the driver’ s and front passenger’ s SRS frontal airbags is / are activated on the first impact, it / they will not be activated on the second impact.
! SRS seat cushion airbag operation s01ah0212
1 Passenger’ s side
The driver’ s and front passenger’ s SRS
1 First impact 2 Second impact
In an accident where the vehicle is impacted more than once, the driver’ s and / or front passenger’ s SRS frontal airbag( s) will deploy only once on the first impact.
Example: In the case of a double collision, first with another vehicle, then against a concrete wall in immediate succession,
WARNING
The SRS seat cushion airbag is designed not to deploy when the seatbelt for the corresponding seat is not fastened. For safety, all persons in the vehicle should fasten their seatbelts.
The SRS seat cushion airbags are designed to deploy simultaneously when the SRS frontal airbags deploy. For details
