! If the passenger ’ s frontal airbag OFF indicator light illuminates and the ON indicator light turns off even when the front passenger ’ s seat is occupied by an adult s01ah020501 |
Dual 7.0-inch display models
: Front passenger ’ s frontal airbag ON indicator light
: Front passenger ’ s frontal airbag OFF indicator light
|
11.6-inch display models : Front passenger ’ s frontal airbag ON indicator light
: Front passenger ’ s frontal airbag OFF indicator light
|
This can be caused by the adult incorrectly sitting in the front passenger ’ s seat .
1 . Turn the ignition switch to the “ LOCK ”/ “ OFF ” position .
2 . Ask the front passenger to set the seatback to the upright position , sit up straight in the center of the seat cushion , correctly fasten the seatbelt , position his / her legs out forward , and adjust the seat to the rearmost position .
3 . Turn the ignition switch to the “ ON ” position .
|
If the OFF indicator light remains illuminated while the ON indicator light remains off , take the following actions .
1 . Turn the ignition switch to the “ LOCK ”/ “ OFF ” position .
2 . Make sure that the front passenger does not use a blanket , extra seat cushion , seat cover , extra seat heater or massager , etc .
3 . If wearing excessive layers of clothing , the front passenger should remove any unnecessary items before sitting in the front passenger ’ s seat , or should sit in a rear seat .
4 . Turn the ignition switch to the “ ON ” position and wait 6 seconds to allow the system to complete self-checking . Following the system check , both indicator lights turn off for 2 seconds . Now , the ON indicator light should illuminate while the OFF indicator light remains off .
If the OFF indicator light still remains illuminated while the ON indicator light remains off , ask the occupant to move to the rear seat and immediately contact your SUBARU dealer for an inspection .
|
1
Seat , Seatbelt and SRS Airbags
|
||||||
– CONTINUED – |
