When any of the tires are punctured , you can seal the tire temporarily . However , do not tow a trailer when a sealed tire is used . We recommend that you consult the nearest SUBARU dealer for details .
The maximum gross trailer weight and maximum gross tongue weight are indicated in the following table .
|
& Connecting a SUBARU Genuine Trailer Hitch s08ak01
1 . Remove the receiver cover from the hitch receiver tube . Then insert the ball mount into the hitch receiver tube .
|
|||
|
Maximum gross trailer weight
3,500 lbs ( 1,588 kg )
2,700 lbs ( 1,224 kg )
|
Maximum gross tongue weight
350 lbs ( 159 kg )
270 lbs ( 122 kg )
|
|||
|
2.4 L models
2.5 L models
When towing a trailer , refer to “ Trailer Towing ( Outback / Subaru Outback Wilderness )” FP473 .
|
2 . Insert the hitch pin into the hole located on the hitch receiver tube so that the pin passes through the ball mount . |
3 . Insert the safety pin through the provided hole on the hitch pin securely .
4 . Check the ball mount assembly by pulling on it to make sure it does not come off the hitch receiver .
|
8
Driving Tips
|
|||
– CONTINUED – |
||||||
