378
Continuously Variable Transmission
the select lever .
If the select lever does not move after performing the above procedure , the shift lock system may be malfunctioning . Contact a SUBARU dealer for an inspection as soon as possible .
& Selection of Manual Mode s07bg02
3 . Remove the grip portion of the screwdriver .
4 . While depressing the brake pedal , insert the screwdriver into the hole , press the shift lock release portion using the screwdriver , and then move
With the vehicle either moving or stationary , move the select lever from the “ D ” position to the “ M ” position to select the manual mode .
1 Upshift indicator 2 Downshift indicator 3 Gear position indicator
When the manual mode is selected , the gear position indicator and upshift indicator and / or downshift indicator on the combination meter illuminate . The gear position indicator shows the currently selected gear in the 1st-to-8th gear range . The upshift and downshift indicators show when a gearshift is possible . When the upshift indicator “ ” is on , upshifting is possible . When the downshift indicator “ ” is on , downshifting is possible . When both indicators are on , upshifting and downshifting are both possible . When the vehicle stops ( for example , at traffic signals ), the downshift indicator turns off .
