Manual Climate Control 317 |
|||||||
|
A
Models with rear ventilators
Heat-def : Windshield defroster outlets , foot outlets and both side outlets of the instrument panel
|
& Temperature Control s04ab05
Perform the following operation to regulate the temperature of airflow from the air outlets .
Temperature control buttons :
Press the temperature control button to the blue side ( cool ) or the red side ( warm ).
Temperature control screen ( 11.6-inch display models ):
1 . Touch the climate control mode indicator .
2 . Select the preferred temperature by the following operation . . Touch and move the temperature control bar . . Touch the “ ”/“ ”. . Touch the preferred temperature in the temperature control screen .
|
! Max A / C mode s04ab0503
For quicker cooling , touch “ MAX A / C ” on the climate control mode select icon or customizable icon .
When the Max A / C mode is on , the following settings will be changed automatically .
. The air conditioner will turn on .
. The temperature will be set on the lowest .
. The fan speed will be set on the
|
maximum speed .
. The air inlet will be set to the recirculation mode .
. The airflow mode setting will be set to the ventilation mode .
To turn off the Max A / C mode and return to the previous setting , touch “ MAX A / C ” again .
! SYNC mode ( 11.6-inch display models ) s04ab0505
When the SYNC mode is turned on , both the driver ’ s and passenger ’ s side temperatures are synchronized using the driver ’ s side temperature control button and temperature control screen .
. If “ SYNC ” is displayed on the customizable icon , touch “ SYNC ” to turn the SYNC mode on or off .
. If a customizable icon other than “ SYNC ” is displayed , touch the climate control mode indicator . Then touch “ SYNC ” to turn the SYNC mode on or off .
The SYNC mode indicator will turn white .
Touch “ SYNC ” again , press the passenger ’ s side temperature control button or operate the passenger ’ s side temperature control bar to cancel the SYNC mode . The SYNC mode indicator will be grayed out . In this case , temperature control on the
|
4
Climate Control
|
|||
– CONTINUED – |
