Mirrors 277 |
||||||||
|
3-18 . Mirrors
s03ap
Always check that the inside and outside mirrors are properly adjusted before you start driving .
& Inside Mirror ( without Auto- Dimming Function ) ( If Equipped ) s03ap08
1 Normal position 2 Anti-glare position
Push the tab on the mirror for normal use . To reduce glare from the headlights of the vehicle behind you , pull the tab to the antiglare position .
|
& Auto-Dimming Mirror / Compass with HomeLink ® ( If Equipped ) s03ap10 |
1 Compass 2 HomeLink ® buttons 3 Switch
During nighttime driving , the auto-dimming feature senses distracting glare from vehicle headlights behind you and automatically dims to eliminate the glare and help preserve your vision .
! To Operate the Auto-Dimming Feature s03ap1001
Press the “ ” switch to turn the autodimming feature on / off . The auto-dimming feature is enabled when the switch ’ s green LED indicator is on . The auto-dimming feature will default to on with each ignition
|
cycle .
! To Operate the Compass Feature ( if equipped ) s03ap1002
1 . To turn the compass feature on / off , press and hold the “ ” switch for more than 3 seconds or until the display turns on / off . The compass feature will default to on with each ignition cycle .
2 . If the display reads “ C ”, slowly drive the vehicle in circles until compass is calibrated .
Compass calibration zones ( U . S .)
|
3
Instruments and Controls
|
||||
– CONTINUED – |
