Center Information Display ( CID ) 225 |
||||||||||
|
! Driver profiles icon s03bs050105
Touch ( driver profiles icon ) to confirm the driver ’ s information . For details , refer to the separate navigation / audio Owner ’ s Manual .
! HOME icon s03bs050106
Touch ( HOME ) to display the top menu .
! Climate control screen s03bs050107
The climate control status is shown on the screen .
|
7 Set temperature indicator ( passenger ’ s side )
8 Front passenger ’ s seat heater / ventilation icon ( if equipped )
9 Customizable icon 10 Fan speed control 11 Climate control ON / OFF icon
When operating the climate control system , the main screen switches to the climate control screen . For details , refer to “ Climate Control Panel ” FP309 .
! Main screen
|
s03bs0502 |
– “ Settings ” ? “ Car ” – “ Car Info ” |
! General settings s03bs050201
Set the time and display general items .
|
1 . Touch ( HOME ). 2 . ? ( Settings ) 3 . ? “ General ” 4 . Select the preferred menu . |
3
Instruments and Controls
|
||||
|
1 Driver ’ s seat heater / ventilation icon ( if equipped )
2 Set temperature indicator ( driver ’ s side ) 3 Airflow mode 4 Climate control mode 5 Air inlet selection 6 SYNC mode indicator
|
To display the main screen , touch ( HOME ).
In this Owner ’ s Manual , the following settings will be explained . For details about other items , refer to the separate navigation / audio Owner ’ s Manual .
– “ Settings ” ? “ General ”
|
|||||||||
– CONTINUED – |
