SRS Airbag (Supplemental Restraint System Airbag) 91
injured should the front passenger’s
SRS frontal airbag deploy. REAR
seats are the safest place for children.
CAUTION
When the front passenger’s seat is
occupied by an infant in an appropriate
child restraint system, observe
the following precautions.
Failure to do so may increase the
load on the front passenger’s seat,
activating the front passenger’s
SRS frontal airbag even though that
seat is occupied by an infant.
. Do not place any article on the
seat other than the infant in the
child restraint system.
. Do not place more than one infant
in the child restraint system.
! If the front passenger’s frontal
airbag ON indicator illuminates
and the OFF indicator turns off
even when an infant or a small
child is in a child restraint system
(including booster seat)
s01ah020401
Dual 7.0-inch display models
: Front passenger’s frontal airbag ON
indicator
: Front passenger’s frontal airbag OFF
indicator
11.6-inch display models
: Front passenger’s frontal airbag ON indicator
: Front passenger’s frontal airbag OFF
indicator
1. Turn the ignition switch to the “LOCK”/
“OFF” position.
2. Remove the child restraint system from
the seat.
3. By referring to the child restraint
manufacturer’s recommendations as well
as the child restraint system installation
procedures in “Child Restraint Systems”
☞P57, correctly install the child restraint
system.
4. Turn the ignition switch to the “ON”
position and make sure that the front
passenger’s frontal airbag ON indicator
turns off and the OFF indicator illuminates.
1
Seat, Seatbelt and SRS Airbags
– CONTINUED –
