52
Seatbelts
fastened to the connector (buckle)
on the right-hand side), it cannot
properly restrain the wearer in position
in an accident, possibly resulting
in serious injury or death.
Rear center seatbelt is stowed in the
recess of the ceiling.
1. Retrieve the connector (tongue) from
the slot in the recess by pulling the
connector (tongue).
2. Pass the seatbelt through the belt
guide.
4. After confirming that the webbing is not
twisted, insert the connector (tongue)
attached at the webbing end into the
buckle on the right-hand side until a click
is heard.
. If the belt stops before reaching the
buckle, return the belt slightly and pull it
out more slowly.
. If the belt still cannot be unlocked, let
the belt retract slightly after giving it a
strong pull, then pull it out slowly again.
3. Make sure that the “ ” mark on the
connector (tongue) and the “ ” mark on
the buckle face outwards.
