44
Rear Seats
Lock release button
1) Unlocked
2) Locked
A) Unlocking marker in red
To return the seatback to its original
position, raise the seatback until it locks
into place and make sure that the unlocking
marker on the lock release button is no
longer visible.
WARNING
When you return the seatback to its
original position, check that the
unlocking marker on the lock release
button is not visible. Also,
shake the seatback slightly to confirm
that it is securely fixed in place.
If the seatback is not securely fixed
in place, the seatback may suddenly
fold down in the event of sudden
braking, or objects may move out
from the cargo area, which could
cause serious injury or death.
& Head Restraint Adjustment
s01ac03
Both the rear window side seats and the
rear center seat are equipped with head
restraints.
WARNING
. Never drive the vehicle with the
head restraints removed because
they are designed to reduce the
risk of serious neck injury in the
event that the vehicle is struck
from the rear. Therefore, when
you remove the head restraints,
you must reinstall all head restraints
to protect vehicle occupants.
. All occupants, including the driver,
should not operate a vehicle
or sit in a vehicle’s seat until the
head restraints are placed in their
proper positions in order to minimize
the risk of neck injury in the
event of a crash.
. The front seat head restraints are
designed to be installed into the
front seats only. The rear seat
head restraints are designed to
be installed into the rear seats
only. Do not attempt to install the
front seat head restraints into the
rear seats, or the rear seat head
restraints into the front seats.
! Rear window side seating position
s01ac0301
1) Head restraint
2) Release button
To raise:
Pull the head restraint up.
To lower:
Push the head restraint down while pressing
the release button on the top of the
seatback.
