Combination Meter Display (Color LCD) 203
. The time spent with the engine
stopped by means of the Auto Start
Stop system is also added to the
journey time.
TPMS screen (U.S.-spec. models):
. Immediately adjust the tire pressure
when the warning light illuminates.
When the tire pressure monitoring
system detects the adjusted tire pressure,
the warning light will turn off and
the tire pressure values will turn to
white.
Compass screen (if equipped):
Navigation screen (if equipped):
3
This screen displays each tire pressure.
When a tire is deflated, the deflated tire
and the tire pressure will be displayed on
the screen in yellow.
NOTE
. The tire pressure values are displayed
several minutes after driving.
. Once the tire pressure monitoring
system detects the low tire pressure,
the tire pressure values will display in
yellow until the system detects the
normal tire pressure.
The direction of the vehicle is displayed.
When the route guidance is set in the
navigation system, this item shows the
navigation route information. For details
about the navigation system, refer to the
separate navigation/audio Owner’s Manual.
Instruments and Controls
– CONTINUED –
