Warning and Indicator Lights
The ABS warning light illuminates together
with the brake system warning light if the
EBD system malfunctions. For further
details of the EBD system malfunction
warning, refer to “Brake System Warning
Light” ☞P182.
NOTE
If the warning light behavior is as
described in the following conditions,
the ABS may be considered normal.
. The warning light illuminates right
after the engine is started but turns off
immediately, remaining off.
. The warning light remains illuminated
after the engine has been started,
but it turns off while driving.
. The warning light illuminates during
driving, but it turns off immediately and
remains off.
When driving with an insufficient battery
voltage such as when the engine is jump
started, the ABS warning light may illuminate.
This is due to the low battery voltage
and does not indicate a malfunction. When
the battery becomes fully charged, the
light will turn off.
& Brake System Warning
Light
WARNING
s03ae10
. Driving with the brake system
warning light on is dangerous.
This indicates your brake system
may not be working properly. If
the light remains illuminated,
have the brakes inspected by a
SUBARU dealer immediately.
. If at all in doubt about whether the
brakes are operating properly, do
not drive the vehicle. Have your
vehicle towed to the nearest
SUBARU dealer for repair.
. If the brake system warning light
illuminates, the electronic parking
brake system may be malfunctioning.
Immediately stop
your vehicle in a safe location,
use tire stops under the tires to
prevent the vehicle from moving
and contact your SUBARU dealer.
For details, refer to “Electronic
Parking Brake” ☞P357.
NOTE
. Even if the brake system warning
light illuminates, if the warning light
behavior is as described in the following
examples, the electronic parking
brake system is not malfunctioning.
– The warning light turns off when
the electronic parking brake is applied
or released.
– The warning light turns off when
the ignition switch is turned to the
“ON” position again.
. The brake system warning light may
illuminate immediately after the engine
is started. However, it is not malfunctioning
if the warning light turns off
after the electronic parking brake is
released.
. The brake system warning light may
illuminate after the electronic parking
brake is frequently applied and released.
However, the electronic parking
brake system is not malfunctioning if
the light turns off after a short period of
time.
. When the engine is started while the
electronic parking brake is applied/
released, the system may judge an
abnormal situation and the warning
light may illuminate. If the warning light
illuminates, turn the ignition switch
once to the “LOCK”/“OFF” position
and then restart the engine. Then,
apply/release the electronic parking
brake. If the warning light turns off,
