Seat, seatbelt and SRS airbags/SRS airbag (Supplemental Restraint System airbag)
! SRS seat cushion airbag operation
S01AH1203
WARNING
The SRS seat cushion airbag is
designed not to deploy when the
seatbelt for the corresponding seat
is not fastened. For safety, all per-
sons in the vehicle should fasten
their seatbelts.
The SRS seat cushion airbags are de-
signed to deploy simultaneously when the
SRS frontal airbags deploy. For details
about the operating conditions, refer to
“SUBARU advanced frontal airbag opera-
tion” F1-57.
The front passenger’s SRS seat cushion
airbag is designed not to deploy in either of
the following conditions.
. The front passenger’s seatbelt is not
fastened (even when the front passenger’s
frontal airbag ON indicator illuminates
while the OFF indicator remains off).
. The front passenger’s frontal airbag ON
indicator is off while the OFF indicator
illuminates.
1)
2)
Driver’s side
Passenger’s side
1-61
NOTE
When the front passenger’s SRS frontal
airbag is deactivated by the occupant
detection system, the front passen-
ger’s SRS seat cushion airbag is also
deactivated.
! SRS side airbag and SRS curtain
airbag operation
S01AH1202
The following airbags deploy indepen-
dently of each other because each has
its own impact sensor.
. Driver’s SRS side airbag
. Front passenger’s SRS side airbag
. SRS curtain airbag (right-hand side)
. SRS curtain airbag (left-hand side)
Therefore, they may not both deploy in the
– CONTINUED –
