7-64
Starting and operating/Reverse Automatic Braking System
When an object is detected in the rever-
sing direction, the range of detected object
will be shown on the audio/navigation
monitor.
A warning alarm will sound and, depend-
ing on the speed, either torque control to
generate engine braking or automatic
braking will be applied.
! Object close behind warning
! Obstacle detected and alert level
S07BN0301
S07BN0302
Long proximity alert (object detected)
1) Green: 35 inches (90 cm) or more
Short proximity alert (approaching the
object closer)
1) Orange: 20 to 28 inches (50 to 70 cm)
Automatic braking warning
1) Warning message
Medium proximity alert (approaching the
object)
1) Yellow: 28 to 35 inches (70 to 90 cm)
Closest proximity alert (too close to the
object)
1) Red: 20 inches (50 cm) or less
If the vehicle continues to go in reverse,
the system may determine the risk of
collision with the object. In this case, short
warning beeps or continuous warning
beeps will sound and either strong auto-
matic braking or torque control will be
applied to prevent collision.
