7-62
Starting and operating/Reverse Automatic Braking System
NOTE
. When the 8-inch audio/navigation
system is performing a software up-
date, the Reverse Automatic Braking
System may not display the following
items on the audio/navigation screen
until the update is complete.
– Display Icon on/off Function
– Distance Indicator Image
– Warning Message
. The Reverse Automatic Braking sys-
tem will operate at vehicle speed be-
tween 1 to 9 mph (1.5 to 15 km/h).
However, stopping the vehicle by auto-
matic hard braking is designed to
operate when the vehicle speed is less
than 3 mph (5 km/h).
& Reverse Automatic Braking
System operation
S07BN03
When Reverse Automatic Braking System
is in operation, an audible warning beeps
will sound in 3 levels to warn the driver of a
potential collision.
While the RAB is operating, a warning
message is displayed on the audio/navi-
gation monitor and the combination meter
display.
