Starting and operating/Reverse Automatic Braking System
party except under the following con-
ditions.
. The vehicle owner has given his/her
consent.
. The disclosure/provision is based
on a court order or other legally en-
forceable request.
. Data that has been modified so that
the user and vehicle cannot be identi-
fied is provided to a research institution
for statistical processing or similar
purposes.
& Reverse Automatic Braking
System overview
! Detecting range
S07BN0101
cancel the system, refer to “Cancel-
ing the Reverse Automatic Braking
system operation” F7-66.
& Operating conditions
S07BN02
1)
S07BN01
The system detects objects using sonar
sensors installed in the rear bumper.
. If the system determines a possible
collision with an object in the reversing
direction, automatic deceleration will be
activated. Also, beeping sounds will acti-
vate.
. If the vehicle is further reversed, auto-
matic hard braking will be applied and a
continuous beeping sound will activate.
7-59
2)
3)
Detecting range (width): Approximately 6
in (15 cm) outside of the vehicle width
Range that the system cannot detect:
Approximately 20 in (50 cm) behind the
rear of the vehicle
Detecting range (length): Approximately
5 ft (1.5 m) from the rear of the vehicle
WARNING
If your vehicle is trapped on a rail-
road crossing and you are trying to
escape by reversing through the
crossing gate, the system may re-
cognize the crossing gate as an
obstacle and brake may activate. In
this case, remain calm and either
continue to depress the accelerator
pedal or cancel the system. To
The Reverse Automatic Braking system
will operate when all of the following
conditions are met.
. The ignition switch is in the “ON”
position
. The EyeSight warning indicator is off
. The RAB warning indicator is off
. HALT (Reverse Automatic Braking sys-
tem OFF) indicator is off
. The Reverse Automatic Braking sys-
tem is set to on
. The select lever is in the “R” position
. The vehicle speed is between 1 to 9
mph (1.5 to 15 km/h)
CAUTION
. In the following cases, the Re-
verse Automatic braking system
will not operate. Promptly con-
tact a SUBARU dealer to have the
system inspected.
– The EyeSight warning indica-
tor is illuminated
– The RAB warning indicator is
– CONTINUED –
