Starting and operating/BSD/RCTA
screen until the update is complete.
& BSD/RCTA approach indica-
tor light/warning buzzer
S07BM03
While the BSD/RCTA is active, the follow-
ing item(s) will operate to alert the driver:
. The BSD/RCTA approach indicator
light (when there are vehicles in the
neighboring lanes).
. The BSD/RCTA approach indicator
light and warning buzzer (when a vehicle
is approaching from the left or right side
while your vehicle is reversing)
! BSD/RCTA approach indicator light
S07BM0301
The indicator light will illuminate when a
vehicle approaching from behind is de-
tected.
The indicator light will flash to warn the
driver of dangers under the following
conditions.
. While the indicator light is illuminating, if
the turn signal lever is operated toward the
side in which this light turned on
. When reversing the vehicle while the
system detects a vehicle approaching
from either side
! BSD/RCTA approach indicator
light dimming function
S07BM030101
When the headlights are turned on, the
brightness of the BSD/RCTA approach
indicator light will be reduced.
NOTE
BSD/RCTA approach indicator light
It is mounted on each side of the outside
mirrors.
. You may have difficulty seeing the
BSD/RCTA approach indicator light
under the following conditions.
– When sunlight shines directly on
it
– When the headlight beams from a
vehicle traveling behind shines di-
rectly on it
. While the illumination brightness
control dial is in the fully upward
position, even if the headlights are
turned on, the brightness of the BSD/
7-53
RCTA approach indicator light will not
be reduced. For details about the
illumination brightness control dial,
refer to “Illumination brightness con-
trol” F3-60.
! BSD/RCTA approach warning buz-
zer (only when reversing)
S07BM0302
A warning buzzer sounds along with
flashing of the BSD/RCTA approach in-
dicator light to warn the driver of dangers.
The setting of the warning buzzer volume
can be changed by operating the multi
information display of the combination
meter. For details, refer to “BSD/RCTA”
F3-47.
! Safety tips regarding the BSD/RCTA
approach indicator light/warning
buzzer
S07BM0303
. In the following cases, operation of the
BSD/RCTA approach indicator light and
the warning buzzer may be delayed or the
system may fail to issue these warnings.
– When a vehicle moves to the neigh-
boring lane from a lane next to the
neighboring lane
– When driving on a steep incline or
on repeated sharp uphill and downhill
grades
– When going beyond a pass
– When both your vehicle and a
– CONTINUED –
