Starting and operating/Remote engine start system (dealer option)
7-21
tery “+” should be pointed away from the
transmitter circuit board on the battery).
4. Carefully snap the case halves back
together, reinstall the phillips screw and
test the remote engine start system.
NOTE
To comply with the FCC RF exposure
compliance requirements, no change
to the antenna or the device is per-
mitted. Any change to the antenna or
the device could result in the device
exceeding the RF exposure require-
ments and void user’s authority to
operate the device.
1. Remove the small phillips screw lo-
cated on the back side of the transmitter.
2. Carefully pry the remote engine start
transmitter halves apart using a small flat-
head screwdriver.
3. Remove the circuit board from the
bottom half of the case and remove the
battery and replace with a new one. Be
sure to observe the (+) sign on the old
battery before removing it to ensure that
the new battery is inserted properly (bat-
– CONTINUED –
