3-80
Instruments and controls/Mirrors
battery be placed in the hand-
held remote (garage door opener
remote) of the device for quicker
and more accurate training.
. Turn the ignition switch to the
“ON” or “ACC” position before
programming and/or operating
HomeLink ® .
. Keep the hand-held remote (gar-
age door opener remote) of the
device you are programming for
use in other vehicles as well as
for future HomeLink ® program-
ming. It is also suggested that
upon the sale of the vehicle, the
programmed HomeLink ® buttons
be erased for security purposes.
Refer to “Erasing HomeLink ® but-
tons” F3-83.
! Programming a New HomeLink ®
button
S03AP100301
1)
1)
2)
Indicator Light
HomeLink ® buttons
1. Press and release the HomeLink ®
button that you would like to program.
The HomeLink ® indicator light will flash
orange slowly (if not, refer to “Erasing
HomeLink ® buttons” F3-83.
Garage door opener remote
2. Position the hand-held remote (garage
door opener remote) 1 to 3 inches (2 to 8
cm) away from the HomeLink ® button that
you would like to program.
NOTE
Some hand-held remotes (garage door
opener remotes) may actually train
better at a distance of 6 to 12 inches
(15 to 20 cm). Keep this in mind if you
have difficulty with the programming
process.
