3-76
Instruments and controls/Mirrors
the hand-held transmitter button and the
desired HomeLink ® button. DO NOT re-
lease the buttons until step 5 has been
completed.
NOTE
Some gate operators and garage door
openers may require you to replace this
programming step 4 with procedures in
“Programming for entrance gates and
garage door openers in Canada” F3-
77.
5. Hold down both buttons until the
HomeLink ® indicator light flashes, first
slowly then rapidly. When the indicator
light flashes rapidly, both buttons may be
released. (The rapidly flashing light indi-
cates successful programming of the new
frequency signal.)
6. Press and hold the programmed button
and check the HomeLink ® indicator light. If
the indicator light stays on continuously,
your garage door should activate and the
programming is completed.
If the indicator light flashes rapidly for 2
seconds and then stays on continuously,
your garage door opener may be protected
by a rolling code feature. In this case you
need to perform the additional steps that
are described in “Programming rolling-
code-protected garage door openers in
the U.S.A.” F3-76.
! Programming rolling-code-pro-
tected garage door openers in
the U.S.A.
S03AP070402
If your garage door opener has a rolling
code feature, program the HomeLink ®
Wireless Control System for it by following
steps 1 through 5 in “Garage door opener
programming in the U.S.A.” F3-75. Then
continue with the following steps.
vary by brand of garage door opener. If it is
difficult to locate the training button, refer
to your garage door opener’s instruction
manual.
NOTE
The assistance of a second person may
make the programming quicker and
easier.
1)
Training button
2. Press the training button on the garage
door opener motor head unit (which
activates the “training light” on the unit).
Proceed to step 3 within 30 seconds.
3. Inside the vehicle, firmly press, hold for
2 seconds and release the HomeLink ®
button that was programmed in the pre-
vious section. Press and release the
button a second time to complete the
programming procedure.
1. Locate the training button on the
garage door opener motor head unit. The
exact location and color of the button may
