Instruments and controls/Mirrors
& Auto-dimming mirror with
HomeLink ® (except U.S.-
spec. models - if equipped)
S03AP07
1)
2)
3)
! In case a problem occurs
S03AP090408
If you cannot activate a device using
the corresponding HomeLink ® button
after programming, contact HomeLink ®
at www.homelink.com or call 1-800-355-
3515 for assistance.
dimming function is on, the LED indicator
will illuminate.
Even with the mirror in the automatic
dimming mode, the mirror surface turns
bright if the select lever is shifted into the
“R” (reverse) position. This is to ensure
good rearward visibility during reversing.
When cleaning the mirror, use a paper
towel or similar material dampened with
glass cleaner. Do not spray glass cleaner
directly on the mirror as that may cause the
liquid cleaner to enter the mirror housing
and damage the mirror.
HomeLink ® button 1
HomeLink ® button 2
HomeLink ® button 3
1. Press and hold the two outer buttons
(button 1 and button 3) until the indicator
light begins to flash (after approximately
20 seconds).
2. Release both buttons.
3-73
! Photosensors
S03AP0701
1)
2)
3)
4)
5)
6)
7)
HomeLink ® button 1
HomeLink ® button 2
LED
HomeLink ® button 3
Sensor
Automatic dimming on button
Automatic dimming off button
The auto-dimming mirror has an anti-glare
feature which automatically reduces glare
coming from headlights of vehicles behind
you. It also contains a HomeLink ® wireless
control system.
By pressing the automatic dimming on/off
button, the automatic dimming function is
turned on or off. When the automatic
The mirror has a photosensor attached on
both the front and back sides. During
nighttime driving, these sensors detect
distracting glare from vehicle headlights
– CONTINUED –
