Instruments and controls/Warning and indicator lights
Warning and indicator lights
S03AE
Several of the warning and indicator lights
illuminate momentarily and then go out
when the ignition switch is initially turned to
the “ON” position. This permits checking
the operation of the bulbs.
Apply the parking brake and turn the
ignition switch to the “ON” position. For
the system check, the following lights
illuminate and turn off after several sec-
onds or after the engine has started:
: Seatbelt warning light
(The seatbelt warning light turns off
only when the driver fastens the seat-
belt.)
: Front passenger’s seatbelt warning
light
(The seatbelt warning light turns off
only when the front seat passenger
fastens the seatbelt.)
: SRS airbag system warning light
ON / : Front passenger’s frontal airbag
ON indicator light
/ : Front passenger’s frontal airbag
OFF indicator light
/ : CHECK ENGINE warning light/
Malfunction indicator light
: Charge warning light for repair.
: Oil pressure warning light & Seatbelt warning light
and chime
: AT OIL TEMP warning light
/
: ABS warning light
: Vehicle Dynamics Control warning light/
Vehicle Dynamics Control operation
indicator light
: Vehicle Dynamics Control OFF indicator
light
/
: Brake system warning light
3-13
S03AE01
Your vehicle is equipped with a seatbelt
warning device at the driver’s and front
passenger’s seat, as required by current
safety standards.
With the ignition switch turned to the “ON”
position, this device reminds the driver and
front passenger to fasten their seatbelts by
the warning lights in the locations indicated
in the following illustration and a chime.
: Hill Holder indicator light
: All-Wheel Drive warning light
: Power steering warning light
: Low tire pressure warning light
(U.S. spec. models)
: Low fuel warning light
: Hill descent control indicator (if
equipped)
: Automatic headlight beam leveler
warning light (if equipped)
Driver’s warning light
If any lights fail to illuminate, it indicates a
burned-out bulb or a malfunction of the
corresponding system.
Consult your authorized SUBARU dealer
– CONTINUED –
