2-36
Keys and doors/Windows
! Operating the window
S02AH0702
With one-touch auto up and down
feature:
1) Automatically close*
2) Close
3) Open
4) Automatically open*
*: To stop the window halfway, operate the
switch to opposite side.
NOTE
. If you continue to hold the AUTO
switch in the down position after the
window has been fully opened, the
circuit breaker may activate for a short
time and the window may not operate.
Allow several seconds for the system
to reset without touching the switch,
and the window will begin to operate
normally on its own.
. If you continue to hold the AUTO
switch in the up position after the
window has fully closed, the circuit
breaker may open and the system may
not operate. After several seconds, the
window will be able to be opened by
holding the switch down until it is fully
opened. The AUTO function will not
operate. The window can be raised by
pulling up on the switch several times
until the window is fully closed.
To reset to normal operation, initialize
the power window to reactivate the one-
touch auto up/down function. Refer to
“Initialization of power window (win-
dows with one-touch auto up/down
function)” F2-37.
. If the vehicle’s battery is discon-
nected due to situations such as bat-
tery or fuse replacement, the one-touch
auto up/down function will be deacti-
vated. Initialize the power window to
reactivate the one-touch auto up/down
function. Refer to “Initialization of
power window (windows with one-
touch auto up/down function)” F2-37.
Without one-touch auto up and down
feature:
1)
2)
Close
Open
To open:
Press the appropriate switch down and
hold it until the window reaches the desired
position.
To close:
Pull the switch up and hold it until the
window reaches the desired position.
