Seat, seatbelt and SRS airbags/Front seatbelt pretensioners
the belt more effectively restrains the
driver.
When a seatbelt pretensioner is activated,
an operating noise will be heard and a
small amount of smoke will be released.
These occurrences are normal and not
harmful. This smoke does not indicate a
fire in the vehicle.
Once the seatbelt pretensioner has been
activated, the seatbelt retractor remains
locked. Consequently, the seatbelt cannot
be pulled out and retracted and therefore
must be replaced.
NOTE
. Seatbelt pretensioners are not designed to activate in minor impacts.
. In cases of rollover accidents, as the
SRS curtain airbags deploy, the seatbelt pretensioners are activated simultaneously.
. In cases of frontal collisions, the
following components will operate simultaneously.
– Seatbelt pretensioner for driver
– Seatbelt pretensioner for front
passenger
– SRS frontal airbag for driver
– SRS frontal airbag for front passenger*
– SRS seat cushion airbag for
driver
– SRS seat cushion airbag for front
passenger*
– SRS curtain airbags (both sides)
(if an offset frontal collision occurs)
*: This does not operate if the occupant
detection system deactivates airbag operation. For details, refer to “Front
passenger’s SRS frontal airbag” F1-52.
. In cases of side collisions, the
following components will operate simultaneously.
– SRS curtain airbag (impacted
side)
– SRS side airbag (impacted side)
(when any of the center pillar impact sensors/front door impact sensors senses an impact force)
– Seatbelt pretensioner for driver
(when the driver’s side front door
impact sensor senses an impact
force)
– Seatbelt pretensioner for front
passenger (when the front passenger’s side front door impact sensor
senses an impact force)
. Pretensioners are designed to function on a one-time-only basis. In the
event that a pretensioner is activated,
both the driver’s and front passenger’s
seatbelt retractor assemblies should
be replaced only by an authorized
1-25
SUBARU dealer. When replacing seatbelt retractor assemblies, use only
genuine SUBARU parts.
. If either front seatbelt does not
retract or cannot be pulled out due to
a malfunction or activation of the
pretensioner, contact your SUBARU
dealer as soon as possible.
. If the front seatbelt retractor assembly or surrounding area has been
damaged, contact your SUBARU dealer
as soon as possible.
. When you sell your vehicle, we urge
you to explain to the buyer that it has
seatbelt pretensioners by alerting the
buyer to the contents of this section.
WARNING
. To obtain maximum protection,
the occupants should sit in an
upright position with their seatbelts properly fastened. Refer to
“Seatbelts” F1-16.
. Do not modify, remove or strike
the front seatbelt retractor assemblies or surrounding area.
This could result in accidental
activation of the seatbelt pretensioners or could make the system inoperative, possibly resulting in serious injury. Seatbelt
– CONTINUED –
