Instruments and controls/Mirrors
WARNING
.
When programming the
HomeLink® Wireless Control System, you may be operating a
garage door opener or other
device. Make sure that people
and objects are out of the way
of the garage door or other
device to prevent potential harm
or damage.
. Do not use the HomeLink® Wireless Control System with a garage door opener that lacks the
safety stop and reverse feature
as required by applicable safety
standards. A garage door opener
which cannot detect an object,
signaling the door to stop and
reverse, does not meet these
safety standards. Using a garage
door opener without these features increases risk of serious
injury or death. For more information, consult the HomeLink®
website at www.homelink.com or
call 1-800-355-3515.
CAUTION
When programming the HomeLink®
Wireless Control System to operate
a garage door opener or an entrance
gate, unplug the device’s motor
from the outlet during programming
to prevent motor burnout.
3-71
NOTE
If any of the HomeLink® buttons are
already programmed for other devices,
skip step 2 because it clears the
memory of all three buttons.
NOTE
. After programming your HomeLink®
Wireless Control System for the desired devices, retain the hand-held
transmitters for further programming
or device testing in the event of a
problem.
. It is recommended that you insert a
new battery in the hand-held transmitter of a device to ensure correct
programming.
! Garage door opener programming in the U.S.A.
NOTE
When programming the HomeLink ®
Wireless Control System for a garage
door opener, it is suggested that you
park the vehicle outside the garage.
1. Unplug the motor of the garage door
opener from the outlet.
1)
2)
3)
HomeLink® button 1
HomeLink® button 2
HomeLink® button 3
2. Press and hold the two outer
HomeLink® buttons (button 1 and button
3) until the indicator light begins to flash
(after approximately 20 seconds). Then
release both buttons.
3. Hold the end of the garage door
opener’s hand-held transmitter between
1 and 3 inches (25 and 76 mm) away from
the HomeLink® button you wish to program.
– CONTINUED –
