Starting and operating/BSD/RCTA
warn the driver of dangers. When rever-
sing the vehicle, the indicator light flashes
when the system detects a vehicle ap-
proaching from either side.
! BSD/RCTA approach indicator
light dimming function
When the headlights are turned on, the
brightness of the BSD/RCTA approach
indicator light will be reduced.
NOTE
. When affected by direct sunlight,
you may have difficulty recognizing
the BSD/RCTA approach indicator light.
. When affected by the headlight
beams from the vehicles behind, you
may have difficulty recognizing the
BSD/RCTA approach indicator light.
. While the illumination brightness
control dial is in the fully upward
position, even if the headlights are
turned on, the brightness of the BSD/
RCTA approach indicator light will not
be reduced. For details about the
illumination brightness control dial,
refer to “Illumination brightness con-
trol” F3-48.
! BSD/RCTA approach warning buz-
zer (only when reversing)
A warning buzzer sounds along with
flashing of the BSD/RCTA approach in-
dicator light to warn the driver of dangers.
The setting of the warning buzzer volume
can be changed by operating the multi
information display of the combination
meter. For details, refer to “BSD/RCTA”
F3-42.
! Safety tips regarding the BSD/RCTA
approach indicator light/warning
buzzer
. In the following cases, operation of the
BSD/RCTA approach indicator light and
the warning buzzer may be delayed or the
system may fail to issue these warnings.
When a vehicle moves to the
neighboring lane from a lane next to
the neighboring lane
When driving on a steep incline or
on repeated sharp uphill and downhill
grades
When going beyond a pass
When both your vehicle and a
vehicle driving on a neighboring lane
are driving on the far side of each lane.
When several narrowly-spaced ve-
hicles are approaching in a row
In low radius bends (tight bends or
7-57
when making turns at an intersection)
When there is a difference in height
between your lane and the neighbor-
ing lane
Immediately after the BSD/RCTA is
activated by pressing the BSD/RCTA
OFF switch
Immediately after the shift lever/
select lever is shifted to the “R”
position
When extremely heavy cargo is
loaded in the trunk or cargo area
. During reversing, operation of the BSD/
RCTA approach indicator light and the
warning buzzer may be delayed or the
system may fail to issue these warnings
under the following conditions.
When backing out of an angled
parking space
When a large-sized vehicle is
parked next to your vehicle (That
vehicle prevents the propagation of
radar waves.)
When reversing on sloped roads
When reversing at a high speed
CONTINUED
