About EyeSight
■ Following distance setting indicator
Indicates the following distance setting that was set with the |
/ |
( Following distance |
setting) switch. |
|
|
� Refer to page 45. |
|
|
■ Set vehicle speed display
Displays the set vehicle speed.
� Refer to pages 38 and 76.
■ Your vehicle indicator
When the brake pedal is depressed or the brake control function is active, the brake light on the indicator illuminates in red.
■ Lane keep Assist indicator
� This indicator illuminates when Lane Keep Assist is turned on by pressing the( Lane Keep Assist) switch.
� While the Lane Keep Assist system is activated, if the vehicle travels across a lane marker the indicator turns from white to green.
� Refer to pages 54 and 58.
■ Selector indicator / shift position indicator
This indicator illuminates and shows which position the selector lever or the gear is in.
■ Lane indicator
� When Lane Keep Assist is in the standby status or is operating, the lane indicator of the detected lane will illuminate( left, right or both left and right).
� Either the left or right indicator blinks depending on which side your vehicle is drifting towards when Lane Departure Warning operates.
� The left and right indicators alternately blink when Lane Sway Warning operates.
� Refer to pages 68 and 71.
■ EyeSight warning indicator( yellow)
� This indicator illuminates or flashes when a malfunction occurs in the EyeSight system.
� When it is illuminated or flashing, none of the EyeSight functions can be used( including Adaptive Cruise Control and the Pre-Collision Braking System, etc.).
� Refer to page 86.
15
