6-22
Interior equipment/Rear view camera
tion cannot be seen on the screen.
CAUTION
The range that can be viewed with
the rear view camera is limited.
Always be sure to check with your
eyes when moving backward and
proceed slowly.
& Help line
Image from camera
Range of view
The area from the rear end of the bumper
can be viewed. Areas at both ends of the
bumper and areas just under the bumper
cannot be viewed.
Also, the image from the rear view camera
looks shorter than the actual distance.
NOTE
For some models, if you shift to the “R”
range within approximately 8 seconds
after turning on the ignition switch,
help line may not be displayed. Wait for
approximately 8 seconds or more after
turning on the ignition switch before
shifting to the “R” range. Then help line
will be displayed.
CAUTION
The range that can be viewed with
the rear view camera is limited.
Always be sure to check with your
eyes when moving backward and
proceed slowly.
The help line (distance marker and vehicle
width line) is a guide to help you realize
the actual distance from the screen.
Image from camera
The area above the camera cannot be
viewed. If there is an object that has a
wide projection on its upper part such as a
sign pole behind the vehicle, the projec-
