About EyeSight
■ Following distance setting indicator
Indicates the following distance setting that was set with the
setting) switch.
Refer to page 45.
/
(Following distance
■ Set vehicle speed display
Displays the set vehicle speed.
Refer to pages 38 and 68.
■ Your vehicle indicator
When the brake pedal is depressed or the brake control function is active, the brake light on
the indicator illuminates in red.
■ Selector indicator/shift position indicator
This indicator illuminates and shows which position the selector lever or the gear is in.
■ EyeSight warning indicator (yellow)
This indicator illuminates or flashes when a malfunction occurs in the EyeSight system.
When it is illuminated or flashing, none of the EyeSight functions can be used (including
Adaptive Cruise Control and the Pre-Collision Braking System, etc.).
Refer to page 78.
■ EyeSight temporary stop indicator (white)
This indicator illuminates when the EyeSight system is temporarily stopped.
When the ignition switch is placed in the ON position, it will illuminate if the
(CRUISE) switch is set to ON within approximately 7 seconds of the engine starting. It
turns off when approximately 7 seconds have elapsed since the engine started.
When it is illuminated, none of the EyeSight functions can be used except for Conventional Cruise Control.
Refer to page 79.
■ Lane Departure Warning OFF indicator light
This indicator illuminates when the Lane Departure Warning and Lane Sway Warning are
off.
It also illuminates when the ignition switch is turned to the ON position, and then approximately 7 seconds after the engine starts, the Lane Departure Warning will be turned on.
The default setting for the Lane Departure Warning when the vehicle is restarted is “ON”.
Refer to page 62.
15
