OUTBACK
D
Headlights/turn signal
3
2
1 Headlights
To turn on, rotate knob to;
: Instrument panel illumination, parking lights, front side
marker lights, rear side marker lights, tail lights and
license plate lights are on.
: Instrument panel illumination, headlights, parking
lights, front side marker lights, rear side marker lights,
tail lights and license plate lights are on.
AUTO : Headlights and the lights mentioned above are
automatically ON/OFF.
: The headlights are all off.
1
3
2 High/low beam change
To change to high beam, push lever forward.
To return, pull back to detent.
To flash high beams, pull lever toward you and release.
3 Turn signal
Move lever up or down.
Even if the ignition key is removed from the ignition switch, the lights can be illuminated by operation the
light control switch position from
(off) to
or
.
To prevent the battery from discharged, before leaving the vehicle, make sure that the light control switch
is turned to
(off).
E
Fog lights (if equipped)
F
Windshield wiper and washer
1
2
3
2 Intermittent time control
To adjust the operating
interval, turn dial.
To turn on, rotate dial to
.
Front fog lights operate only when
headlight switch is in...
position.
- AUTO position and the
headlights are on.
G
1 Wiper
To operate, push lever down/up
to the following positions:
: Mist (for a single wipe)
: Off
: Intermittent
: Low speed
: High speed
3 Washer
To wash the windshield, pull the
wiper control lever toward you.
Rear window wiper and washer
Wiper
To operate, rotate knob to;
: Continuous
: Intermittent
: Off
Washer
Rotate knob to
In the intermittent position, when you move the
select lever to the R position (AT and CVT) or
the shift lever to the reverse position (MT), the
rear wiper will switch to continuous operation.
When you move the select lever/shift lever from
the R (reverse)position to another position, the
rear wiper will return to intermittent operation.
. The washer fluid sprays and the wiper operates.
