Audio/Bluetooth® audio
Bluetooth® audio
NOTE
For models with the genuine SUBARU
navigation system, refer to the Owner’s
Manual supplement for the navigation
system.
NOTE
The Bluetooth word mark and logo are
registered trademarks of Bluetooth
SIG, Inc.
This function enables you to play back
audio sources from Bluetooth® audio
devices. You need to register the Bluetooth® audio device in the system before
using it.
NOTE
. The Bluetooth® audio function may
not operate properly under the following conditions.
– The device is turned off.
– The battery of the device has run
down.
– The device is not connected to
the system.
– The device is behind the seat or
in the glove box.
– A metal material is covering or
touching the device.
. Depending on the type of device that
is used, operation and sound volume
may be different from normal use of
those devices.
. The sound quality may degrade due
to the influence of the device that is
connected to the system or the circumstances of the Bluetooth network.
. When another Bluetooth® device is
simultaneously connected, noise may
be heard.
& Media format
Bluetooth® audio devices cannot be
connected if they are not compatible with
the following Bluetooth® profiles.
. A2DP (Advanced Audio Distribution
Profile)
5-39
. AVRCP (Audio/Video Remote Control
Profile)
& Setting Bluetooth® audio
(type A audio)
1. Select “BT-A SETUP” by pressing the
“MENU” button.
2. Perform the following procedure by
operating the “TUNE” dial while “BT-A” is
displayed.
NOTE
You cannot set Bluetooth® audio while
driving.
! Registering (pairing) device
NOTE
Only one device can be registered.
1. Select the “PAIR AUDIO” menu.
– If a device is already registered,
“MEMORY FULL” is displayed and the
mode changes to the Bluetooth®
audio setting mode.
2. After the passkey is shown on the
display, input the passkey into the device.
– If the registering procedure is finished, “PAIRED” and the name of the
device are displayed.
– If the registering procedure was not
successful, “FAILED” is displayed.
– CONTINUED –
