Audio/CD player operation
! Selecting preset channels
1. Press the “SAT” button to select SAT1,
SAT2 or SAT3 reception.
2. Press the preferred preset button
to
) briefly.
(from
& When the following messages are displayed (type B
audio)
If one of the following messages is
displayed when receiving XM signals,
determine the cause based on the following information. If you cannot clear these
messages, contact your SUBARU dealer.
Message
Status
CHECK ANTENNA
The antenna cannot be
detected because it
has become disconnected, etc.
NO SIGNAL
There is no reception
because the system
cannot obtain signals
that are strong enough.
LOADING
The system temporarily
cannot be used because it is currently
receiving signals or is
decoding.
The channel that has
CHANNEL OFF AIR been selected is currently off air.
CHAN UNAVAILABLE
The service cannot
currently be used.
CH UNAUTHORIZED
A channel for which
you do not have a
subscription has been
selected.
5-19
CD player operation
CAUTION
This is a class I laser product. Use of
controls or adjustments or performance of procedures other than
those specified herein may result
in hazardous radiation exposure. Do
not open covers and do not attempt
to repair this unit by yourself. Refer
servicing to qualified personnel.
NOTE
. Make sure to always insert a disc
with the label side up. If a disc is
inserted with the label side down, the
player displays “CHECK DISC”.
Refer to “When the following messages
are displayed” F5-25.
. If a disc is inserted during a radio
broadcast, the disc will interrupt the
broadcast.
. After the last track finishes, the disc
will automatically return to track 1 (the
first track on the disc) and will automatically play back.
. The player is designed to be able to
play music CD-Rs and music CD-RWs,
but it may not be able to play certain
– CONTINUED –
