Seat, seatbelt and SRS airbags/*SRS airbag (Supplemental Restraint System airbag)

The SRS side airbag and SRS curtain
airbag are not designed to deploy in most
rear impacts because the SRS side airbag
and SRS curtain airbag deployment would
not help the occupant in those situations.

! Examples of the types of accidents in which the SRS curtain
airbag will most likely deploy

2)

1-59

An offset frontal collision that is severe
enough to deploy the front airbag.

Legacy models

Each SRS side airbag and SRS curtain
airbag are designed to function on a onetime-only basis.
! Example of the type of accident
in which the SRS side airbag will
most likely deploy

A severe side impact near the front seat
activates the SRS side airbag.

1)

A severe side impact near the front seat
or the rear seat.
– CONTINUED –
