Seat, seatbelt and SRS airbags
Front seatbelt pretensioners
effectively.
The pretensioner sensor also serves as a
SRS frontal airbag sensor. If the sensor
detects a certain predetermined amount of
force during a frontal collision, the front
seatbelt is quickly drawn back in by the
retractor to take up the slack so that the
belt more effectively restrains the front
seat occupant.
1)
2)
Seatbelt retractor assembly (shoulder
belt pretensioner)
Lap belt pretensioner
The driver’s and front passenger’s seatbelts have a seatbelt pretensioner. The
seatbelt pretensioners are designed to be
activated in the event of an accident
involving a moderate to severe frontal
collision.
The shoulder belt pretensioner is supplemented by a lap belt pretensioner, which is
located at the base of the center pillar.
Like the shoulder belt pretensioner, the lap
belt pretensioner instantaneously pulls in
the belt to eliminate slack if a certain level
of frontal collision force is detected. As a
result, the belt restrains the driver more
When a seatbelt pretensioner is activated,
an operating noise will be heard and a
small amount of smoke will be released.
These occurrences are normal and not
harmful. This smoke does not indicate a
fire in the vehicle.
Once the seatbelt pretensioner has been
activated, the seatbelt pretensioner remains locked. Consequently, the seatbelt
cannot be pulled out and retracted and
therefore must be replaced.
NOTE
. Seatbelt pretensioners are not designed to activate in minor frontal
impacts, in side or rear impacts or in
roll-over accidents.
. The driver’s and passenger’s seatbelt pretensioners and frontal airbag
operate simultaneously.
. Pretensioners are designed to function on a one-time-only basis. In the
1-23
event that a pretensioner is activated,
both the driver’s and front passenger’s
seatbelt retractor assemblies must be
replaced and only by an authorized
SUBARU dealer. When replacing seatbelt retractor assemblies, use only
genuine SUBARU parts.
. If either front seatbelt does not
retract or cannot be pulled out due to
a malfunction or activation of the
pretensioner, contact your SUBARU
dealer as soon as possible.
. If the front seatbelt assembly or
surrounding area has been damaged,
contact your SUBARU dealer as soon
as possible.
. When you sell your vehicle, we urge
you to explain to the buyer that it has
seatbelt pretensioners by alerting the
buyer to the contents of this section.
WARNING
. To obtain maximum protection,
occupants should sit in an upright position with their seatbelts
properly fastened. Refer to “Seatbelts” F1-14.
. Do not modify, remove or strike
the front seatbelt assemblies or
surrounding area. This could
result in accidental activation of
– CONTINUED –
