Consumer information and Reporting safety defects
sidewall, or innerliner that extends
to cord material.
. Outer diameter
The overall diameter of an inflated
new tire.
. Overall width
The linear distance between the
exteriors of the sidewalls of an
inflated tire, including elevations
due to labeling, decorations, or
protective bands or ribs.
. Passenger car tire
A tire intended for use on passenger cars, multipurpose passenger
vehicles, and trucks, that have a
gross vehicle weight rating (GVWR)
of 10,000 lbs (4,535 kg) or less.
. Ply
A layer of rubber-coated parallel
cords.
. Ply separation
A parting of rubber compound
between adjacent plies.
mounted on an automotive wheel,
provides the traction and contains
the gas or fluid that sustains the
load.
. Production options weight
The combined weight of those
installed regular production options
weighing over 5.1 lbs (2.3 kg) in
excess of those standard items
which they replace, not previously
considered in curb weight or accessory weight, including heavy duty
brakes, ride levelers, roof rack,
heavy duty battery, and special
trim.
. Radial ply tire
A pneumatic tire in which the ply
cords that extend to the beads are
laid at substantially 90 degrees to
the centerline of the tread.
. Recommended inflation pres-
sure
. Pneumatic tire
The cold inflation pressure recommended by a vehicle manufacturer.
A mechanical device made of rubber, chemicals, fabric and steel or
other materials, that, when
A tire designed to operate at higher
loads and at higher inflation pres-
. Reinforced tire
13-7
sures than the corresponding standard tire.
. Rim
A metal support for a tire or a tire
and tube assembly upon which the
tire beads are seated.
. Rim diameter
Nominal diameter of the bead seat.
. Rim size designation
Rim diameter and width.
. Rim type designation
The industry of manufacturer’s designation for a rim by style or code.
. Rim width
Nominal distance between rim
flanges.
