3-52
Instruments and controls
mode, with the function indicator in orange, every time the shift lever/select
lever is shifted into the “R” (reverse)
position.
glass cleaner. Do not spray glass
cleaner directly on the mirror surface.
By doing so, the sprayed glass cleaner
could enter the inside of the mirror
housing. That may cause a malfunction
in the mirror.
! Rear view image display
When the ignition switch is in the “ON”
position and the shift lever/select lever is
in the “R” (reverse) position, the rear view
camera automatically displays the rear
view image behind the vehicle on the
inside mirror.
Also, the following help lines are indicated
as a guide to help you realize the actual
distance from the display.
If the ignition switch is turned to the
”LOCK”/OFF” position, the display setting
returns to the on mode as a default setting
the next time the ignition switch is turned
to the “ON” position.
1)
2)
3)
4)
5)
Vehicle width line (oblique vertical line)
Approx. 10 feet (3 m) from the bumper
(green horizontal line)
Approx. 6.5 feet (2 m) from the bumper
(green horizontal line)
Approx. 3 feet (1 m) from the bumper
(yellow horizontal line)
Approx. 1.5 feet (0.5 m) from the bumper
(red horizontal line)
By pressing the power on button while the
shift lever/select lever is in the “R”
(reverse) position, the rear view image
display turns to the on mode. By pressing
the power off button while the shift lever/
select lever is in the “R” (reverse) position,
the rear view image display turns to the off
mode.
Once the rear view image display is set to
the off mode, the display stays in the off
! Language mode change
The language mode of the captions on the
rear view image display is selectable in
English or French in the following ways.
1. Press and hold the power on button for
6 to 12 seconds while the shift lever/select
lever is in the “R” (reverse) position, and
then release it. The display will enter the
language selection mode.
2. Briefly press the power on button to
toggle the captions on the display in
English or French.
3. By releasing the power on button for 5
seconds, the display blinks one time to
show that the language mode is selected.
! Non-operational mode
The rear view image display can be set as
non-operational. After setting the display
to the non-operational mode, the display
does not show the rear view image even if
