Instruments and controls
! Gear position indicator setting (MT
models)
The gear position indicator light can be
activated or deactivated by performing the
following procedure.
1. Turn the ignition switch to the “LOCK”/
“OFF” position.
2. Press the trip knob to show “
” or
“
” on the trip meter display.
The display can be switched as shown in
the following illustration by pressing the
trip knob.
NOTE
. The initial setting for your vehicle of
the gear position indicator has been set
for activation “
” at the time of
shipment from the factory.
. It is not possible to change the
setting of the gear position indicator
when the ignition switch is in the “ON”
position. Change the setting when the
ignition switch is in the “LOCK”/“OFF”
or “Acc” position.
& Turn signal indicator
lights
Type B
1) Upshift/downshift indicator (AT and CVT
models)
These lights show the operation of the turn
signal or lane change signal.
If the indicator lights do not blink or blink
rapidly, the turn signal bulb may be burned
out. Replace the bulb as soon as possible.
Refer to “Replacing bulbs” F11-43.
This indicator shows the position of the
shift lever (MT models) or select lever (AT
and CVT models).
! Upshift/downshift indicator (AT and
CVT models)
