Pre-Collision Braking System
Turning off the Pre-Collision Braking System
Pressing and holding the Pre-Collision Braking System OFF switch for approximately 2 seconds (or longer) turns off the Pre-Collision Braking System (including Pre-Collision Brake
Assist). When this control is turned off, the Pre-Collision Braking System OFF indicator light
on the instrument panel illuminates. To turn the control back on, press and hold the PreCollision Braking System OFF switch for approximately 2 seconds or longer again. When
this control is turned on, the Pre-Collision Braking System OFF indicator light turns off.
OFF
OFF
S00377
S00580
NOTE
When the Pre-Collision Braking System is turned off,
Throttle Management Control function is also turned off.
Even when the Pre-Collision Braking System is turned
switch is turned off and the engine is then restarted,
Braking System will be turned on. The system default
vehicle is restarted in “ON”.
the Pre-Collision
off, if the ignition
the Pre-Collision
setting when the
I Pre-Collision Braking System OFF indicator light
This indicator light illuminates when the
ignition switch is turned to the ON position,
and then flashes for approximately 7 seconds
after the engine starts. It turns off when the
Pre-Collision Braking System is turned off.
It also illuminates under the following
conditions.
When the VDC OFF switch is pressed and
VDC is canceled
When the EyeSight system has a
malfunction
* Refer to page 71.
When the EyeSight system has stopped
temporarily
* Refer to page 72.
48
S00531
