Starting and operating 7-25 constant brake pedal pressure. Do not pump the brake pedal since doing so may defeat the operation of the ABS system.
The ABS system prevents the lock-up of wheels which may occur during sudden braking or braking on slippery road surfaces. This helps prevent the loss of steering control and directional stability caused by wheel lock-up.
When the ABS system is operating, you may hear a chattering noise or feel a slight vibration in the brake pedal. This is normal when the ABS operates.
The ABS system will not operate when the vehicle speed is below approximately 6 mph( 10 km / h).
& ABS system self-check
You may feel a slight shock in the brake pedal and hear the operating sound of ABS from the engine compartment just after the vehicle is started. This is caused by an automatic functional test of the ABS system being carried out and does not indicate any abnormal condition.
& ABS warning light
Refer to“ ABS warning light” F3-16.
Electronic Brake Force Distribution( EBD) system
The EBD system maximizes the effectiveness of the brakes by allowing the rear brakes to supply a greater proportion of the braking force. It functions by adjusting the distribution of braking force to the rear wheels in accordance with the vehicle’ s loading condition and speed.
The EBD system is an integral part of the ABS system and uses some of the ABS system’ s components to perform its function of optimizing the distribution of braking force. If any of the ABS components used by the EBD function fails, the EBD system also stops working.
When the EBD system is operating, you may hear a chattering noise or feel a slight vibration in the brake pedal. This is normal and does not indicate a malfunction.
& Steps to take if EBD system malfunctions
If a malfunction occurs in the EBD system, the system stops working and the brake system warning light and ABS warning light illuminate simultaneously.
The EBD system may be malfunctioning if the brake system warning light and ABS warning light illuminate simultaneously during driving.
Even if the EBD system fails, the conventional braking system will still function. However, the rear wheels will be more prone to locking when the brakes are applied harder than usual and the vehicle’ s motion may therefore become somewhat harder to control.
If the brake system warning light and ABS – CONTINUED –
