Map Disc Loading
When changing the map disc with a disc that is appropriate to the current location, or when updating the map disc while in the version
upgrade of a map disc, it is necessary to change it with another map
disc by following the procedure described below.
NOTE
• When changing a map disc with another one, be sure to stop the vehicle in a
safe location.
• For details of the map discs, see "Map Discs". (See Page 49.)
1
2
Press the map disc eject button.
3
When the map disc is ejected, take it out.
4
Insert a map disc that contains the area showing the current position.
The monitor automatically returns to the normal condition to start
the loading of the disc.
With the ignition switch on, open the cover of the map
disc slot.
NOTE
Support the upper side of the cover with your thumb, pull the notch located on
the center of the under side of the cover, and then remove the cover.
CAUTION
• You must insert the map disc into the second slot from
the top.
• When inserting a map disc, do not insert 2 or more map
discs together. This may cause the mechanism to malfunction.
22 Navigation
