Starting and operating
Shift up
mph (km/h)
1st to 2nd
15 (24)
2nd to 3rd
25 (40)
3rd to 4th
40 (64)
4th to 5th
45 (72)
5th to 6th
50 (80)
enter the red area if these speeds are
exceeded.
With the exception of cases where sudden
acceleration is required, the vehicle
should not be driven with the tachometer’s
needle inside the red area. Failure to
observe this precaution can lead to
excessive engine wear and poor fuel
economy.
mph (km/h)
! Maximum allowable speeds
WARNING
1)
Slider
You must raise the slider and hold it in that
position before you can move the shift
lever to the “R” position.
To change gears, fully depress the clutch
pedal, move the shift lever, and gradually
let up on the clutch pedal.
If it is difficult to shift into gear, put the
transmission in neutral, release the clutch
pedal momentarily, and then try again.
& Shifting speeds
! Recommended shifting speeds
The best compromise between fuel economy and vehicle performance during
normal driving is ensured by shifting up
at the speeds listed in the following table.
When shifting down a gear, ensure
that the vehicle is not travelling at a
speed exceeding the Maximum Allowable Speed for the gear which is
about to be selected. Failure to
observe this precaution can lead to
engine over-revving and this in turn
can result in engine damage.
In addition, sudden application of
engine brakes when the vehicle is
travelling on a slippery surface can
lead to wheel locking; as a consequence, control of the vehicle may
be lost and the risk of an accident
increased.
The following table shows the maximum
speeds that are possible with each different gear. The tachometer’s needle will
7-17
Legacy
Gear
Non-turbo
models
Turbo
models
Outback
32 (52)
1st
32 (52)
35 (56)
2nd
57 (92)
62 (100)
57 (92)
3rd
86 (138)
94 (151)
86 (139)
4th
114 (184)
125 (201)
115 (185)
NOTE
Never exceed posted speed limits.
& Driving tips
Do not drive with your foot resting on the
clutch pedal and do not use the clutch to
hold your vehicle at a standstill on an
upgrade. Either of those actions may
caus
