Radio functions Listening to the radio It is possible to tune in to a radio station to listen to the AM or FM radio. 1 Change the source over to the FM or AM radio. (See Page 118.) 2 Tune in to a station. (See Page 126.) When no FM radio screen is displayed while listening to the FM radio, press the button or the button on the steering switch to display the FM radio screen. (2) (3) (2) Waveband display The difference between the FM1 and FM3 frequency bands is displayed. (3) Station tuned in to The name of the station tuned in to and its frequency are displayed. When the station is preset, the preset number is also displayed. FM radio screen is displayed (1) (1) Clock The current time is displayed. (4) (5) (6) (7) (4) ST Displayed while in the stereophonic. (5) VOL The volume level is displayed. (See Page 121.) (6) SCAN Displayed when scanning a station to which you can tune in. (See Page 127.) (7) Preset keys 1 to 6 It is possible to preset a station and select it later. (See Page 129.) (8) (8) (9) (10) (11) (SETTING) Select this key to display the screen set for the audio. (See Page 195.) Audio and Visual 123
