1-38
Seat, seatbelt and SRS airbags
*SRS airbag (Supplemental
Restraint System airbag)
*SRS: This stands for supplemental restraint system. This name is used because the airbag system supplements the
vehicle’s seatbelts.
Your vehicle is equipped with a crash
sensing and diagnostic module, which will
record the use of the seatbelt by the front
passenger when any of the SRS frontal,
side and curtain airbags deploys.
3. Fasten the top tether hook of the child
restraint system to the appropriate upper
anchorage.
4. Tighten the top tether securely.
& Models with SRS airbags and
lap/shoulder restraints for
driver, front passenger, and
window-side rear passengers
Your vehicle is equipped with a supplemental restraint system in addition to a
lap/shoulder belt at each front seating
position and each rear window-side seating position. The supplemental restraint
system (SRS) consists of six airbags.
The configurations are as follows:
. Driver’s and front passenger’s frontal
airbags
. Driver’s and front passenger’s side
airbags
. Curtain airbags (for driver, front passenger, and window-side rear passen-
gers)
These SRS airbags are designed only
as a supplement to the primary protection provided by the seatbelt.
The system also controls front seatbelt
pretensioners. For operation instructions
and precautions concerning the seatbelt
pretensioner, refer to “Front seatbelt pretensioners” F1-22.
WARNING
. To obtain maximum protection in
the event of an accident, the
driver and all passengers in the
vehicle should always wear seatbelts when the vehicle is moving.
The SRS airbag is designed only
as a supplement to the primary
protection provided by the seatbelt. It does not do away with the
need to fasten seatbelts. In combination with the seatbelts, it
offers the best combined protection in case of a serious accident.
Not wearing a seatbelt increases
the chance of severe injury or
death in a crash even when the
vehicle has the SRS airbag.
For instructions and precautions
concerning the seatbelt system,
